MuonautMuon Time Dilation / Length ContractionSticker
Muonaut – Muon Time Dilation / Length Contraction Physics Sticker
- Size
- 3" × 3"
- Surface
- White
- Made
- To order · shipping times
Muonaut is a Pixelated Physics law character, one of our relativity and cosmos designs. Muons live only 2.2 µs yet reach the ground: time dilation stretches their clocks, and in their frame the sky is short. This is a 3" × 3" pixel-art sticker. The physics panel below gives the equation, what each symbol means and the sources.
Couldn't load pickup availability
Details
Size3″ × 3″
3″ × 3″ kiss-cut sticker.
Shipping
Free US shipping · $10 flat shipping outside the US, whatever's in your order.
Returns & replacements21 days
Every item is printed to order, so we can’t accept returns or exchanges for change of mind, or if you ordered the wrong size or colour.
Print defect, misprint, damage or the wrong item? We’ll send a free replacement, or a refund if you prefer. Report it within 21 days of delivery with a photo; no need to send it back.
∂ The physics
Muonaut is born about 15 km up, in the spray of particles a cosmic ray knocks out of the upper air, and she is not built to last.
A muon at rest lives on average 2.197 microseconds before it decays. That is the mean life; the half-life is shorter, 1.52 μs. Even at almost the speed of light, one mean life carries her only about 659 m, the last line on this page. Without relativity, very few muons born that high would survive the 15 km to the ground. Plenty do.
The ground’s account is time dilation. She is moving fast, so by the station’s clocks her lifetime stretches by the Lorentz factor γ, the first lines. At γ = 23 her 2.2 μs becomes about 50 μs, just what the 15 km trip takes at nearly light speed.
Her own account is different and just as right. In her frame she is at rest and her clock runs normally. It is the atmosphere that rushes past, contracted by the same factor: 15 km squashed to about 0.65 km, roughly one mean life’s flight. Same arrival, two consistent stories.
Bruno Rossi and David Hall tested it in 1941, comparing muon decay at different altitudes in Colorado, and found that faster muons lived longer, as relativity requires. In 1963 David Frisch and James Smith did it cleanly: they counted muons on Mount Washington in New Hampshire and again near sea level, about 1900 m lower, and far more survived the descent than their resting lifetime allowed.
Muonaut doesn’t argue with the station clock. She just points out of the window.
In my frame, the sky is short.
Equations
| Symbol | Meaning | Unit |
|---|---|---|
| \(\Delta t\) | muon lifetime as timed by clocks on the ground | \(\mathrm{s}\) |
| \(\tau\) | mean lifetime in the muon's own rest frame (PDG 2024: 2.1969811 μs; the half-life is shorter, 1.52 μs) | \(\mathrm{s}\) |
| \(\gamma\) | Lorentz factor | \(\mathrm{1}\) |
| \(L_0\) | thickness of the atmosphere in the ground frame | \(\mathrm{m}\) |
| \(L\) | the same thickness measured in the muon's frame | \(\mathrm{m}\) |
| \(v\) | muon speed | \(\mathrm{m/s}\) |
| \(c\) | speed of light in vacuum | \(\mathrm{m/s}\) |
Sources
- Rossi & Hall (1941) Variation of the Rate of Decay of Mesotrons with Momentum, Phys. Rev. 59, 223 (opens in a new tab)
- Frisch & Smith (1963) Measurement of the Relativistic Time Dilation Using μ-Mesons, Am. J. Phys. 31, 342 (opens in a new tab)
- Particle Data Group (2024) Review of Particle Physics — muon listing (mean life 2.1969811 ± 0.0000022 μs) (opens in a new tab)
